SAR图像目标识别的可解释性问题探讨

郭炜炜, 张增辉, 郁文贤, 孙效华

雷达学报 (2020)

摘要/Abstract

SAR Automatic Target Recognition (ATR) is a key task in microwave remote sensing. Recently, Deep Neural Networks (DNNs) have shown promising results in SAR ATR. However, despite the success of DNNs, their underlying reasoning and decision mechanisms operate essentially like a black box and are unknown to users. This lack of transparency and explainability in SAR ATR pose a severe security risk and reduce the users’ trust in and the verifiability of the decision-making process. To address these challenges, in this paper, we argue that research on the explainability and interpretability of SAR ATR is necessary to enable development of interpretable SAR ATR models and algorithms, and thereby, improve the validity and transparency of AI-based SAR ATR systems. First, we present recent developments in SAR ATR, note current practical challenges, and make a plea for research to improve the explainability and interpretability of SAR ATR. Second, we review and summarize recent research in and practical applications of explainable machine learning and deep learning. Further, we discuss aspects of explainable SAR ATR with respect to model understanding, model diagnosis, and model improvement toward a better understanding of the internal representations and decision mechanisms. Moreover, we emphasize the need to exploit interpretable SAR feature learning and recognition models that integrate SAR physical characteristics and domain knowledge. Finally, we draw our conclusion and suggest future work for SAR ATR that combines data and knowledge-driven methods, human–computer cooperation, and interactive deep learning.

合成孔径雷达(SAR)图像目标识别是实现微波视觉的关键技术之一。尽管深度学习技术已被成功应用于解决SAR图像目标识别问题,并显著超越了传统方法的性能,但其内部工作机理不透明、解释性不足,成为制约SAR图像目标识别技术可靠和可信应用的瓶颈。深度学习的可解释性问题是目前人工智能领域的研究热点与难点,对于理解和信任模型决策至关重要。该文首先总结了当前SAR图像目标识别技术的研究进展和所面临的挑战,对目前深度学习可解释性问题的研究进展进行了梳理。在此基础上,从模型理解、模型诊断和模型改进等方面对SAR图像目标识别的可解释性问题进行了探讨。最后,以可解释性研究为切入点,从领域知识结合、人机协同和交互式学习等方面进一步讨论了未来突破SAR图像目标识别技术瓶颈有可能的方向。

相关信息/Info

作者/Authors

链接/Link

郭炜炜, 张增辉, 郁文贤, 孙效华

https://radars.ac.cn/article/doi/10.12000/JR20059

图片/Figures
